ZAW411WL-TT-AZ

Emergency light Self-contained
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications

Robust, zinc die-cast wall surface-mounted luminaire for illuminating escape and emergency routes near exits in accordance with DIN EN 60598-1, DIN EN 60598-2-22 and DIN EN 1838.
Concealed screw connection for an attractive design. Available as luminaire with a central battery system or LED single battery.

Kabelllose zentrale Steuerung und Überwachung für große Installationen von bis zu 50.000 Leuchten mit Wireless Professional.


Product data

Luminaire type
Sicherheitsleuchte
Supply
Einzelbatterie
Mounting
Wandaufbau
Monitoring
Wireless Professional (WL)
Pictograph
Nein
Bridging time
1 h
Illuminant
LED
Battery
LiFePO4 3,2 V/3,3 Ah
Housing material
Zink-Druckguss
Operating mode
Bereitschaftsschaltung / Dauerschaltung
Housing color
Anthrazit
Input voltageAC
230 V
Protection type (IP)
IP65
Input frequency
50 / 60 Hz
Impact resistance (IK)
8
Input voltage DC
- V
Certification
WEEE, CE, 5 Jahre Garantie
Power max.
5,3 W
Insulation class
1
Power maintained
3,9 W
Power non-maintained
1,5 W
Ambient temperature maintained mode
-25 °C bis 40 °C
Ambient temperature non-maintained mode
-25 °C bis 40 °C
Depth
65 mm
Width
315 mm
Height
140 mm
Weight
2.11
Weight incl. packaging
2.23
Connection cross-section
2.5 mm²
Switching input
Ja
Emergency light blocking
Nein
Battery connection
Stecker
Dimming function
Nein
Luminous flux mains
190 lm
Luminous flux emergency
190 lm
Customs tariff number
94056180
EAN
4260766557934
Luminaire type
Sicherheitsleuchte
Mounting
Wandaufbau
Pictograph
Nein
Illuminant
LED
Housing material
Zink-Druckguss
Housing color
Anthrazit
Protection type (IP)
IP65
Impact resistance (IK)
8
Certification
WEEE, CE, 5 Jahre Garantie
Insulation class
1
Supply
Einzelbatterie
Monitoring
Wireless Professional (WL)
Bridging time
1 h
Battery
LiFePO4 3,2 V/3,3 Ah
Operating mode
Bereitschaftsschaltung / Dauerschaltung
Input voltageAC
230 V
Input frequency
50 / 60 Hz
Input voltage DC
- V
Power max.
5,3 W
Power maintained
3,9 W
Power non-maintained
1,5 W
Ambient temperature maintained mode
-25 °C bis 40 °C
Ambient temperature non-maintained mode
-25 °C bis 40 °C
Depth
65 mm
Width
315 mm
Height
140 mm
Weight
2.11
Weight incl. packaging
2.23
Connection cross-section
2.5 mm²
Switching input
Ja
Emergency light blocking
Nein
Battery connection
Stecker
Dimming function
Nein
Luminous flux mains
190 lm
Luminous flux emergency
190 lm
Customs tariff number
94056180
EAN
4260766557934

Recommended areas of application

Bildungseinrichtungen
Versammlungsstätten
Sportstätten
Parkhaus
Einzelhandel
Hotel & Gastronomie
Bürogebäude
Industrie
Medizin- & Pflegeeinrichtungen
Transport & Verkehr
