XPMU011SC

Safety luminaire Single Battery
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications

Polycarbonate cylinder safety luminaire with explosion protection for gas and dust Ex zones.

Prepared for two cable entries for feed-through wiring. By attaching a pictogram, can also be used as an emergency exit sign luminaire.

By means of mounting adapter for wall/ceiling mounting or suspension by means of eye bolt.

Labelling according to 2014/34/EC (ATEX)

Zone 1 / zone 21 gas and dust

- Ex d IIB T6 Gb / Ex d IIB T6 Gb
- Ex t IIIC T85ºC Db


Manufactured in accordance with
-EN 60079-0:2018, EN 60079-1:2014, EN 60079-31:2014

-Certified by INERIS 20ATEX0005X

Automatic monitoring of safety luminaire with SelfControl.


Product data

Luminaire type
Safety luminaire
Monitoring
SelfControl (SC)
Mounting
Universal
Bridging time
1 h
Pictograph
No
Battery
6 V/1,6Ah Ah
Illuminant
LED
Operating mode
Standby circuit / permanent circuit
Housing material
Aluminum die-cast, Polycarbonate
Input voltageAC
230 V
Protection type (IP)
IP66
Input frequency
50 / 60 Hz
Impact resistance (IK)
5
Power max.
40 W
Certification
WEEE, CE
Power DS
40 W
Insulation class
1
Power BS
3 W
Supply
Single Battery
Ambient temperature DS
0 °C - 40 °C
Ambient temperature BS
0 °C - 40 °C
Depth
750 mm
Width
157 mm
Height
197 mm
Weight
5.5
Weight incl. packaging
6.4
Connection cross-section
2.5 mm²
Switching input
No
Emergency light blocking
Yes
Battery connection
Clip
Dimming function
No
Luminous flux mains
4600 lm
Luminous flux emergency
750 lm
Customs tariff number
94051190
EAN
4260659564582
Luminaire type
Safety luminaire
Mounting
Universal
Pictograph
No
Illuminant
LED
Housing material
Aluminum die-cast, Polycarbonate
Protection type (IP)
IP66
Impact resistance (IK)
5
Certification
WEEE, CE
Insulation class
1
Supply
Single Battery
Monitoring
SelfControl (SC)
Bridging time
1 h
Battery
6 V/1,6Ah Ah
Operating mode
Standby circuit / permanent circuit
Input voltageAC
230 V
Input frequency
50 / 60 Hz
Power max.
40 W
Power DS
40 W
Power BS
3 W
Ambient temperature DS
0 °C - 40 °C
Ambient temperature BS
0 °C - 40 °C
Depth
750 mm
Width
157 mm
Height
197 mm
Weight
5.5
Weight incl. packaging
6.4
Connection cross-section
2.5 mm²
Switching input
No
Emergency light blocking
Yes
Battery connection
Clip
Dimming function
No
Luminous flux mains
4600 lm
Luminous flux emergency
750 lm
Customs tariff number
94051190
EAN
4260659564582

Recommended areas of application

Educational institutions
Places of assembly
Sports facilities
Car park
Retail trade
Hotel & Gastronomy
Office building
Industry
Medical & care facilities
Transport & Traffic
