WFXW019

Exit sign Centralised power supply systems
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications

Modern emergency exit sign wall luminaire in a square format.

For identifying escape and emergency routes. As an option, the luminaire can be used to identify other adjoining rooms.

The high level of protection can be ensured thanks to the easy-to-mount bayonet catch, making the luminaire suitable for varied use.

The requested pictogram (arrow to the right, left, up or down) is supplied as standard.


Product data

Luminaire type
Exit sign
Insulation class
2
Mounting
Wall mounting
Supply
Centralised power supply systems
Recognition distance
30 m
Monitoring
Without monitoring
Pictograph
acc. to Specification
Bridging time
CPS
Illuminant
LED
Battery
/
Housing material
Plastic
Operating mode
Permanent circuit
Housing color
white
Input voltageAC
230 V
Protection type (IP)
IP65
Input frequency
50 / 60 Hz
Impact resistance (IK)
4
Input voltage DC
100-254 V
Certification
WEEE, CE, D-Sign
Power max.
4,6 W
Power DS
4,6 W
Power BS
0 W
Ambient temperature DS
-20 °C to 40 °C
Ambient temperature BS
-20 °C to 40 °C
Depth
300 mm
Width
300 mm
Height
110 mm
Weight
1.34
Weight incl. packaging
1.59
Connection cross-section
1.5 mm²
Switching input
No
Emergency light blocking
No
Battery connection
No
Dimming function
No
Luminous flux mains
520 lm
Luminous flux emergency
520 lm
Customs tariff number
94056180
EAN
4260682158468
Luminaire type
Exit sign
Mounting
Wall mounting
Recognition distance
30 m
Pictograph
acc. to Specification
Illuminant
LED
Housing material
Plastic
Housing color
white
Protection type (IP)
IP65
Impact resistance (IK)
4
Certification
WEEE, CE, D-Sign
Insulation class
2
Supply
Centralised power supply systems
Monitoring
Without monitoring
Bridging time
CPS
Battery
/
Operating mode
Permanent circuit
Input voltageAC
230 V
Input frequency
50 / 60 Hz
Input voltage DC
100-254 V
Power max.
4,6 W
Power DS
4,6 W
Power BS
0 W
Ambient temperature DS
-20 °C to 40 °C
Ambient temperature BS
-20 °C to 40 °C
Depth
300 mm
Width
300 mm
Height
110 mm
Weight
1.34
Weight incl. packaging
1.59
Connection cross-section
1.5 mm²
Switching input
No
Emergency light blocking
No
Battery connection
No
Dimming function
No
Luminous flux mains
520 lm
Luminous flux emergency
520 lm
Customs tariff number
94056180
EAN
4260682158468

Recommended areas of application

Educational institutions
Places of assembly
Sports facilities
Car park
Retail trade
Hotel & Gastronomy
Office building
Industry
Medical & care facilities
Transport & Traffic
