FLU50ML

Safety luminaire Centralised power supply systems
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications

Robust ceiling-mounted Aluminium die-cast luminaire for the lighting of escape and rescue routes according to DIN EN 60598-1, DIN EN 605982-22 and EN 1838.

The IP66 flood light is suitable for indoor and outdoor use. Due to the wide beam angle, large areas can be easily illuminated. The MU05 monitoring module is installed in the supplied separate housing.

Control and monitoring via central power supply system.


Product data

Luminaire type
Safety luminaire
Supply
Centralised power supply systems
Mounting
Universal
Monitoring
Central power supply (ML)
Pictograph
No
Bridging time
CPS
Illuminant
LED
Battery
/
Housing material
Zinc die-cast
Operating mode
Standby circuit
Housing color
Anthracite
Input voltageAC
230 V
Protection type (IP)
IP66
Input frequency
50 / 60 Hz
Impact resistance (IK)
8
Input voltage DC
216 V
Certification
WEEE, CE
Power max.
51,5 W
Insulation class
1
Power DS
51,5 W
Power BS
1,5 W
Ambient temperature DS
-25 °C to 40 °C
Ambient temperature BS
-25 °C to 40 °C
Depth
247 mm
Width
187 mm
Height
37 mm
Weight
6.5
Weight incl. packaging
6.75
Switching input
No
Emergency light blocking
No
Battery connection
No
Dimming function
No
Luminous flux mains
7000 lm
Luminous flux emergency
7000 lm
Customs tariff number
94054210
EAN
4260682159793
Luminaire type
Safety luminaire
Mounting
Universal
Pictograph
No
Illuminant
LED
Housing material
Zinc die-cast
Housing color
Anthracite
Protection type (IP)
IP66
Impact resistance (IK)
8
Certification
WEEE, CE
Insulation class
1
Supply
Centralised power supply systems
Monitoring
Central power supply (ML)
Bridging time
CPS
Battery
/
Operating mode
Standby circuit
Input voltageAC
230 V
Input frequency
50 / 60 Hz
Input voltage DC
216 V
Power max.
51,5 W
Power DS
51,5 W
Power BS
1,5 W
Ambient temperature DS
-25 °C to 40 °C
Ambient temperature BS
-25 °C to 40 °C
Depth
247 mm
Width
187 mm
Height
37 mm
Weight
6.5
Weight incl. packaging
6.75
Switching input
No
Emergency light blocking
No
Battery connection
No
Dimming function
No
Luminous flux mains
7000 lm
Luminous flux emergency
7000 lm
Customs tariff number
94054210
EAN
4260682159793

Recommended areas of application

Educational institutions
Places of assembly
Sports facilities
Car park
Retail trade
Hotel & Gastronomy
Office building
Industry
Medical & care facilities
Transport & Traffic
