PMW428WL

Emergency light Self-contained
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications

Plastic safety luminaire with convex shaped surround.

To help with mounting, levelling screws are integrated to compensate for uneven surfaces.

The luminaire can be mounted by fitting on the wall and ceiling as well as fitting in the ceiling in conjunction with the mounting frame available.

Wireless central control and monitoring for large installations of up to 50,000 luminaires with Wireless Professional. The luminaire is fitted with the innovative flexible plug-in system for rapid use of the right lens. The hall lens is supplied with every luminaire. A round lens, spotlight lens and beam lens are available as options.


Product data

Luminaire type
Emergency light
Supply
Self-contained
Mounting
Universal
Monitoring
Wireless Professional (WL)
Pictograph
No
Bridging time
8 h
Illuminant
LED
Battery
LiFePO4 6,4 V/3,3 Ah
Housing material
Polycarbonate
Operating mode
Non-maintained / maintained
Housing color
White
Input voltageAC
230 V
Protection type (IP)
IP65
Input frequency
50 Hz
Impact resistance (IK)
6
Power max.
7,5 W
Certification
WEEE, CE, 5 years warranty, HACCP
Power maintained
5,7 W
Insulation class
2
Power non-maintained
0,8 W
Ambient temperature maintained mode
-5 °C to 40 °C
Ambient temperature non-maintained mode
-5 °C to 40 °C
Depth
65 mm
Width
236 mm
Height
136 mm
Weight
0.86
Weight incl. packaging
0.99
Connection cross-section
2.5 mm²
Switching input
Yes
Emergency light blocking
Yes
Battery connection
Connector
Dimming function
Yes
Luminous flux mains
250 lm
Luminous flux emergency
245 lm
Customs tariff number
94056120
EAN
4260766552366
Luminaire type
Emergency light
Mounting
Universal
Pictograph
No
Illuminant
LED
Housing material
Polycarbonate
Housing color
White
Protection type (IP)
IP65
Impact resistance (IK)
6
Certification
WEEE, CE, 5 years warranty, HACCP
Insulation class
2
Supply
Self-contained
Monitoring
Wireless Professional (WL)
Bridging time
8 h
Battery
LiFePO4 6,4 V/3,3 Ah
Operating mode
Non-maintained / maintained
Input voltageAC
230 V
Input frequency
50 Hz
Power max.
7,5 W
Power maintained
5,7 W
Power non-maintained
0,8 W
Ambient temperature maintained mode
-5 °C to 40 °C
Ambient temperature non-maintained mode
-5 °C to 40 °C
Depth
65 mm
Width
236 mm
Height
136 mm
Weight
0.86
Weight incl. packaging
0.99
Connection cross-section
2.5 mm²
Switching input
Yes
Emergency light blocking
Yes
Battery connection
Connector
Dimming function
Yes
Luminous flux mains
250 lm
Luminous flux emergency
245 lm
Customs tariff number
94056120
EAN
4260766552366
