AMW401SC-E

Exit sign
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications

Modern zinc die-cast emergency exit sign luminaire for surface mounting on the wall and for identifying emergency and escape routes.

It is part of the A series luminaire family, which provides solutions for any mounting and has won the German Design Award for its uniform, straight-line design.

Automatic monitoring of safety luminaire with SelfControl. The innovative integrated lens holder with a rapid fitting fixture permits the flexible use of various lens types. Using the right lens allows the distribution of light to be matched perfectly to the application and simplifies illumination which satisfies all relevant standards. A round lens and hall lens are supplied with every luminaire, allowing it to be adapted perfectly to the respective mounting situation. Other lenses, such as a spotlight lens, beam lens or H lens, are available as options.


Product data

Luminaire type
Exit sign
Insulation class
2
Mounting
Wall mounting
Monitoring
SelfControl (SC)
Recognition distance
22 m
Bridging time
1 h
Pictograph
Set
Battery
LiFePO4 6,4 V/1,2 Ah
Illuminant
LED
Power max.
4,2 W
Housing material
Zinc die-cast
Power DS
3,3 W
Housing color
Stainless steel
Power BS
0,9 W
Protection type (IP)
IP40
Ambient temperature DS
-5 °C - 40 °C
Impact resistance (IK)
≥ 3
Ambient temperature BS
-5 °C - 40 °C
Certification
WEEE, CE, ENEC
Depth
50 mm
Width
236 mm
Height
151 mm
Weight
1.33
Weight incl. packaging
1.69
Customs tariff number
94056180
EAN
4260766555077
Luminaire type
Exit sign
Mounting
Wall mounting
Recognition distance
22 m
Pictograph
Set
Illuminant
LED
Housing material
Zinc die-cast
Housing color
Stainless steel
Protection type (IP)
IP40
Impact resistance (IK)
≥ 3
Certification
WEEE, CE, ENEC
Insulation class
2
Monitoring
SelfControl (SC)
Bridging time
1 h
Battery
LiFePO4 6,4 V/1,2 Ah
Power max.
4,2 W
Power DS
3,3 W
Power BS
0,9 W
Ambient temperature DS
-5 °C - 40 °C
Ambient temperature BS
-5 °C - 40 °C
Depth
50 mm
Width
236 mm
Height
151 mm
Weight
1.33
Weight incl. packaging
1.69
Customs tariff number
94056180
EAN
4260766555077

Recommended areas of application

Educational institutions
Places of assembly
Sports facilities
Car park
Retail trade
Hotel & Gastronomy
Office building
Industry
Medical & care facilities
Transport & Traffic


Accessories
