AMR401SC-E

Exit sign
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications
Characteristics and certifications

Modern zinc die-cast emergency exit sign luminaire for recessed mounting in the wall and for identifying emergency and escape routes.

It is part of the A series luminaire family, which provides solutions for any mounting and has won the German Design Award for its uniform, straight-line design.

Automatic monitoring of safety luminaire with SelfControl. Planning certainty is provided by tool-free, variable use of the pictograms on site. A set of pictograms corresponding to DIN ISO 7010 (arrow to the right, left, up and down) is supplied as standard.


Product data

Luminaire type
Exit sign
Insulation class
2
Mounting
Recessed wall mounting
Monitoring
SelfControl (SC)
Recognition distance
22 m
Bridging time
1 h
Pictograph
Set
Battery
LiFePO4 6,4 V/1,2 Ah
Illuminant
LED
Power max.
4,2 W
Housing material
Zinc die-cast
Power DS
3,3 W
Housing color
Stainless steel
Power BS
0,9 W
Protection type (IP)
IP40
Ambient temperature DS
-5 °C to 40 °C
Impact resistance (IK)
≥ 3
Ambient temperature BS
-5 °C to 40 °C
Certification
WEEE, CE, 5 earys warranty
Depth
79 mm
Width
236 mm
Height
151 mm
Installation length
176 mm
Installation width
68 mm
Installation height
40 mm
Weight
1.1
Weight incl. packaging
1.46
Customs tariff number
94056180
EAN
4260766554957
Luminaire type
Exit sign
Mounting
Recessed wall mounting
Recognition distance
22 m
Pictograph
Set
Illuminant
LED
Housing material
Zinc die-cast
Housing color
Stainless steel
Protection type (IP)
IP40
Impact resistance (IK)
≥ 3
Certification
WEEE, CE, 5 earys warranty
Insulation class
2
Monitoring
SelfControl (SC)
Bridging time
1 h
Battery
LiFePO4 6,4 V/1,2 Ah
Power max.
4,2 W
Power DS
3,3 W
Power BS
0,9 W
Ambient temperature DS
-5 °C to 40 °C
Ambient temperature BS
-5 °C to 40 °C
Depth
79 mm
Width
236 mm
Height
151 mm
Installation length
176 mm
Installation width
68 mm
Installation height
40 mm
Weight
1.1
Weight incl. packaging
1.46
Customs tariff number
94056180
EAN
4260766554957

Recommended areas of application

Educational institutions
Places of assembly
Sports facilities
Car park
Retail trade
Hotel & Gastronomy
Office building
Industry
Medical & care facilities
Transport & Traffic


Accessories

  • BALLPLX-AM
    PRODUCT
  • AM-XBE
    PRODUCT
